| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 6252-61-6610 | Plate | 861243- | |
| 2 | 01010-81030 | Bolt | 861243- | |
| 3 | 01643-31032 | Washer | 861243- | |
| 4 | 6252-61-6620 | Bracket | 861243- | |
| 5 | 01010-81030 | Bolt | 861243- | |
| 6 | 01643-31032 | Washer | 861243- | |
| 7 | 6252-61-6510 | Hose | 861243- | |
| 8 | 07281-00197 | Clamp | 861243- | |
| 9 | 6215-51-5970 | Spacer | 861243- | |
| 10 | 01011-81000 | Bolt | 861243- | |
| 11 | 01643-31032 | Washer | 861243- | |
| 12 | 600-051-2160 | Clip | 861243- | |
| 13 | 6215-51-5970 | Spacer | 861243- | |
| 14 | 01011-81005 | Bolt | 861243- | |
| 15 | 01643-31032 | Washer | 861243- | |
| 16 | 600-051-2160 | Clip | 861243- | |
| 17 | 6252-61-6521 | Hose | 861491- | |
| 17 | 6252-61-6520 | Hose | 861243-861490 | |
| 18 | 07281-00197 | Clamp | 861243- | |
| 19 | 01010-81025 | Bolt | 861243- | |
| 20 | 01643-31032 | Washer | 861243- | |
| 21 | 600-051-2160 | Clip | 861243- | |
| 22 | 6252-61-6630 | Bracket | 861243- | |
| 23 | 6631-11-5630 | Spacer | 861243- | |
| 24 | 01010-E1055 | Bolt | 861243- | |
| 25 | 6144-11-5630 | Spacer | 861243- | |
| 26 | 01010-81055 | Bolt | 861243- | |
| 27 | 01643-31032 | Washer | 861243- | |
| 28 | 600-051-2160 | Clip | 861243- | |
| 29 | 6252-51-8260 | Bracket | 861243- | |
| 30 | 01010-81025 | Bolt | 861243- | |
| 31 | 01643-31032 | Washer | 861243- | |
| 32 | 01010-81016 | Bolt | 861243- | |
| 33 | 01643-31032 | Washer | 861243- | |
| 34 | 600-051-2160 | Clip | 861243- | |
| 35 | 6252-61-6640 | Bracket | 861243- | |
| 36 | 01010-81080 | Bolt | 861243- | |
| 37 | 01643-31032 | Washer | 861243- | |
| 38 | 600-051-2160 | Clip | 861243- | |
| 39 | 6252-21-7520 | Hose | 861243- | |
| 40 | 07281-00197 | Clamp | 861243- |
