| Item | Part No. | Part Name | Qty | Serial No. |
| (209-60-73504) | MOTOR ASS'Y | 10239-10999 | ||
| (\0\209-60-73503) | MOTOR ASS'Y | 10105-10238 | ||
| (\0\209-60-73502) | MOTOR ASS'Y | 10053-10104 | ||
| (\0\209-60-73501) | MOTOR ASS'Y | 10001-10052 | ||
| KBB011B-12006 | CYLINDER BLOCK ASS'Y | 10105-10999 | ||
| KB2046B-61214 | CYLINDER BLOCK ASS'Y | 10053-10104 | ||
| KB2046B-61213 | CYLINDER BLOCK ASS'Y | 10001-10052 | ||
| 1 | \6\ | CYLINDER BLOCK | 10105-10999 | |
| 1 | \6\ | CYLINDER BLOCK | 10053-10104 | |
| 1 | \6\ | CYLINDER BLOCK ASS'Y | 10001-10052 | |
| 2 | KBB0111-23002 | PLATE, VALVE | 10105-10999 | |
| 2 | \6\ | PLATE, VALVE | 10053-10104 | |
| 2 | \6\ | PLATE, VALVE | 10001-10052 | |
| 3 | \6\ | PISTON ASS'Y | 10001-10999 | |
| KB2046B-61006 | RETAINER PLATE ASS'Y | 10105-10999 | ||
| KB2046B-61004 | RETAINER PLATE ASS'Y | 10001-10104 | ||
| 4 | \6\ | PLATE, RETAINER | 10001-10999 | |
| 5 | \6\ | HOLDER, RETAINER | 10105-10999 | |
| 5 | \6\ | HOLDER, RETAINER | 10001-10104 | |
| 6 | KB20461-67421 | SHAPAN | 10001-10999 | |
| 7 | KB20461-62006 | CASE, OIL SEAL | 10001-10999 | |
| 8 | KB20461-66904 | BEARING, ROLLER | 10001-10999 | |
| 9 | KB20461-60401 | BEARING, NEEDLE | 10001-10999 | |
| 10 | KB20461-61601 | RACE, INNER | 10001-10999 | |
| 11 | KB20461-61801 | COLLAR | 10001-10999 | |
| 12 | KB20461-61315 | SPRING | 10001-10999 | |
| 13 | KB20461-70802 | PIN | 10105-10999 | |
| 13 | KB20461-70801 | PIN | 10001-10104 | |
| 14 | KB20461-69301 | WASHER | 10001-10999 | |
| 15 | KB20461-68604 | RING, SNAP | 10001-10999 | |
| 16 | KB20461-68602 | RING, SNAP | 10001-10999 | |
| 17 | KB20461-68605 | RING, SNAP | 10001-10999 | |
| 18 | KB92703-16500 | BOLT, SOCKET HEAD | 10001-10999 | |
| 19 | KB20461-62104 | SEAL, OIL (K1) | 10001-10999 | |
| 20 | KB20461-65213 | O-RING (K1) | 10001-10999 | |
| 21 | KB95123-11500 | O-RING (K1) | 10001-10999 | |
| 22 | KB20461-69409 | PISTON, BRAKE | 10001-10999 | |
| 23 | KB20461-69603 | PLATE, FRICTION | 10001-10999 | |
| 24 | KB20461-69602 | PLATE, FRICTION | 10001-10999 | |
| 25 | KB20461-69503 | PLATE, DISK | 10001-10999 | |
| 26 | KB20461-61314 | SPRING | 10001-10999 | |
| 27 | KB20941-63109 | O-RING (K1) | 10001-10999 | |
| 28 | KB95113-01000 | O-RING (K1) | 10001-10999 | |
| 29 | KB15096-01010 | PLUG | 10001-10999 | |
| 30 | KB20461-61311 | SPRING | 10001-10999 | |
| 31 | KB20461-69205 | BALL, STEEL | 10001-10999 | |
| 32 | KB20461-42401 | PLUG | 10001-10999 | |
| 33 | KB95113-01400 | O-RING (K1) | 10001-10999 | |
| 34 | KB20461-65104 | RING, BACK-UP (K1) | 10001-10999 | |
| 35 | KB20461-65105 | RING, BACK-UP (K1) | 10001-10999 | |
| 36 | KB95113-03400 | O-RING (K1) | 10001-10999 | |
| 37 | KB95113-02000 | O-RING (K1) | 10001-10999 | |
| K1 | KB2046A-65125 | REPAIR KIT | 10001-10999 | |
| 1 | KB95113-01800 | O-RING | 10001-10999 | |
| 1 | KB95113-00500 | O-RING | 10001-10999 | |
| 1 | KB95712-00500 | RING, BACK-UP | 10001-10999 | |
| 1 | KB95113-00600 | O-RING | 10001-10999 | |
| 1 | KB95712-00600 | RING, BACK-UP | 10001-10999 | |
| 1 | KB95113-01000 | O-RING | 10001-10999 | |
| 1 | KB95113-01200 | O-RING | 10001-10999 | |
| 1 | KB95113-01800 | O-RING | 10001-10999 | |
| 1 | KB95113-02100 | O-RING | 10001-10999 | |
| 1 | KB21001-00182 | O-RING | 10001-10999 | |
| 1 | KB95712-01200 | RING | 10001-10999 | |
| 1 | KB95712-01800 | RING | 10001-10999 | |
| 1 | KB95713-02100 | RING, BACK-UP | 10001-10999 | |
| 1 | KB95113-01100 | O-RING | 10001-10999 | |
| 1 | KB95113-01800 | O-RING | 10001-10999 | |
| 1 | KB20461-65213 | O-RING | 10001-10999 | |
| 1 | KB20461-62104 | SEAL, OIL | 10001-10999 | |
| 1 | KB20461-65213 | O-RING | 10001-10999 | |
| 1 | KB95123-11500 | O-RING | 10001-10999 | |
| 1 | KB20941-63109 | O-RING | 10001-10999 | |
| 1 | KB95113-01000 | O-RING | 10001-10999 | |
| 1 | KB95113-01400 | O-RING | 10001-10999 | |
| 1 | KB20461-65104 | RING, BACK-UP | 10001-10999 | |
| 1 | KB20461-65105 | RING, BACK-UP | 10001-10999 | |
| 1 | KB95113-03400 | O-RING | 10001-10999 | |
| 1 | KB95113-02000 | O-RING | 10001-10999 |
