| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 02760-00325 | Hose | 65001- | |
| 2 | 02760-00328 | Hose, Face Seal Type | 65001- | |
| 3 | 02760-00331 | Hose, Face Seal Type | 65001- | |
| 4 | 20Y-62-22790 | Band, Red | 65001- | |
| 5 | 20Y-62-22810 | Band, Yellow | 65001- | |
| 6 | 04434-53412 | Clip | 65001- | |
| 7 | 02760-00312 | Hose, Face Seal Type | 65001- | |
| 8 | 04435-51612 | Clip | 65001- | |
| 9 | 04434-51612 | Clip | 65001- | |
| 10 | 01010-81225 | Bolt | 65001- | |
| 11 | 01643-31232 | Washer | 65001- | |
| 12 | 02760-00304 | Hose, Face Seal Type | 65001- | |
| 13 | 21N-62-36660 | Hose | 65001- | |
| 14 | 02760-003A8 | Hose, Face Seal Type | 65001- | |
| 15 | 21M-62-14870 | Hose | 65001- | |
| 16 | 02760-003A9 | Hose, Face Seal Type | 65001- | |
| 17 | 21M-62-14860 | Hose | 65001- | |
| 18 | 02760-00318 | Hose, Face Seal Type | 65001- | |
| 19 | 20Y-62-22810 | Band, Yellow | 65001- | |
| 20 | 20Y-62-22830 | Band, White | 65001- | |
| 21 | 20Y-62-22840 | Band, Black | 65001- | |
| 22 | 20Y-62-22850 | Band, Green | 65001- | |
| 23 | 02896-11009 | O-ring | 65001- | |
| 24 | 21T-06-11950 | Clip | 65001- | |
| 25 | 02761-00308 | Hose, Face Seal Type | 65001- | |
| 26 | 21M-62-14850 | Hose | 65001- | |
| 27 | 20Y-62-22820 | Band, Blue | 65001- | |
| 28 | 20Y-62-22840 | Band, Black | 65001- | |
| 29 | 02896-11009 | O-ring | 65001- | |
| 30 | 04435-51812 | Clip | 65001- | |
| 31 | 01010-81230 | Bolt | 65001- | |
| 32 | 01643-31232 | Washer | 65001- | |
| 33 | (02782-10311) | Elbow | - | |
| 34 | (21N-64-36680) | Tee | - | |
| 35 | (02782-10311) | Elbow | - | |
| (02782-10311) | Elbow | - |
