| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 418-923-3932 | Motor, Wiper | 90216-91201 | |
| 2 | 02030-70444 | Bolt, Unified | 90216-91201 | |
| 3 | 419-926-4260 | Washer | 90943-91201 | |
| 3 | 01643-70623 | Washer | 90216-90942 | |
| 4 | 423-926-4781 | Arm Assembly, Wiper | 90216-91201 | |
| 4 | ND857199-0320 | Accessory Assembly | 90216-91201 | |
| 4 | ND857056-1540 | Nut | 90216-91201 | |
| 4 | ND857059-0020 | Screw | 90216-91201 | |
| 5 | 425-54-15250 | Wiper Blade | 90216-91201 | |
| 5 | 425-56-21220 | Rubber | 90216-91201 | |
| 6 | 421-926-3612 | Motor, Wiper | 90216-91201 | |
| 7 | 01010-80816 | Bolt | 90216-91201 | |
| 8 | 01643-30823 | Washer | 90216-91201 | |
| 9 | 425-925-3360 | Arm, Wiper | 90216-91201 | |
| 10 | 426-925-3930 | Connector | 90216-91201 | |
| 11 | 20U-54-24850 | Wiper Blade | 90216-91201 | |
| 12 | 424-926-3890 | Spacer | 90216-91201 | |
| 13 | 421-926-4311 | Cover | 90216-91201 | |
| 14 | 426-56-31890 | Collar | 90216-91201 | |
| 15 | 426-56-31870 | Washer | 90216-91201 | |
| 16 | 23S-55-51970 | Washer | 90216-91201 | |
| 17 | 01225-70620 | Screw, Philips Head | 90216-91201 | |
| 18 | 01225-70616 | Screw, Philips Head | 90216-91201 | |
| 19 | 423-925-4890 | Hose | 90216-91201 | |
| 20 | 20U-54-46520 | Hook, Sticker Type | 90216-91201 | |
| 21 | 08034-40521 | Band | 90216-91201 | |
| 22 | 421-07-15110 | Joint | 90216-91201 |
