| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 418-43-27191 | Pedal | 90047-91201 | |
| 2 | 363-43-37410 | Pad | 90047-91201 | |
| 3 | 417-43-27410 | Boot | 90047-91201 | |
| 4 | 417-43-27420 | Spring | 90047-91201 | |
| 5 | 418-43-27140 | Rod | 90047-91201 | |
| 6 | 423-43-47361 | Sheet | 90047-91201 | |
| 7 | 01010-81065 | Bolt | 90047-91201 | |
| 8 | 01643-31032 | Washer | 90047-91201 | |
| 9 | 423-43-47350 | Spacer | 90047-91201 | |
| 10 | 01582-11210 | Nut | 90047-91201 | |
| 11 | 04256-41230 | Joint, Ball | 90047-91201 | |
| 12 | 01595-01210 | Nut, Flanged | 90047-91201 | |
| 13 | 01643-31232 | Washer | 90047-91201 | |
| 14 | 04256-41230 | Joint, Ball | 90047-91201 | |
| 15 | 01595-01210 | Nut, Flanged | 90047-91201 | |
| 16 | 01643-31232 | Washer | 90047-91201 | |
| 17 | 01582-11210 | Nut | 90047-91201 | |
| 18 | 418-43-37140 | Rod | 90047-91201 | |
| 19 | 418-43-37130 | Plate | 90047-91201 | |
| 20 | 01010-81270 | Bolt | 90047-91201 | |
| 21 | 01643-31232 | Washer | 90047-91201 | |
| 22 | 417-43-27120 | Shaft | 90047-91201 | |
| 23 | 423-43-47341 | Lever | 90047-91201 | |
| 24 | 06124-02520 | Bearing | 90047-91201 |
