| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | WB0303 | FITTING - 45 DEG | ||
| 2 | HA5597 | HOSE | ||
| 3 | C1540 | LOCKWASHER - 1/2" | ||
| 4 | TR6008 | FLAT WASHER - 1/2" | ||
| 5 | TR1376 | CAPSCREW - 1/2" - 13NC X 1 1/4" | ||
| 6 | C1523 | NUT - 1/2" | ||
| 7 | VC7674 | CLAMP | ||
| 8 | ED8799 | STRAP | ||
| 9 | TZ8029 | BAR, TAPPED | ||
| 10 | TZ8035 | BOX, REFUELING | ||
| 11 | PB2154 | RECEIVER, REFUELING ASSEMBLY | ||
| 12 | PB2020 | CAP | ||
| 13 | WB0479 | FITTING, ADAPTOR | ||
| 14 | TG5720 | CAPSCREW - 3/8" - 13NC X 1" | ||
| 15 | TC1231 | LOCKWASHER - 3/8" | ||
| 16 | TC1233 | NUT - 3/8" |
