| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 232-23-12110 | SHAFT | 1003- | |
| 2 | 06002-32220 | BEARING | .- | |
| \0\06000-32220 | BEARING | 1003-. | ||
| 3 | 232-23-12120 | GEAR | 1003- | |
| 4 | 06004-00315 | BEARING | 1003- | |
| 5 | 232-23-12130 | WASHER | 1003- | |
| 6 | 232-23-12140 | LOCK | 1003- | |
| 7 | 01000-31225 | BOLT | 1003- | |
| 8 | 232-23-12150 | BUSHING | 1003- | |
| 232-23-05110 | SHIM ASS'Y | 1003- | ||
| 9 | 232-23-12180 | SHIM¤ 0.1MM (KIT) | 1003- | |
| 232-23-12170 | SHIM¤ 0.2MM (KIT) | 1003- | ||
| 232-23-12160 | SHIM¤ 0.5MM (KIT) | 1003- | ||
| 10 | 01000-31640 | BOLT | 1153- | |
| 01004-61640 | BOLT | 1003-1152 | ||
| 04059-01616 | WIRE | 1003-1152 | ||
| 11 | 232-23-12190 | WASHER | 1153- | |
| 01640-21635 | WASHER | 1003-1152 | ||
| 12 | 232-23-12210 | PLATE | 1003- | |
| 13 | 232-23-12220 | RETAINER | 1003- | |
| 14 | 232-23-12230 | GASKET (KIT) | 1003- | |
| 15 | 01000-31016 | BOLT | 1153- | |
| 01004-31016 | BOLT | 1003-1152 | ||
| 04059-01616 | WIRE | 1003-1152 | ||
| 16 | 01602-01030 | WASHER | 1153- | |
| 17 | 232-23-12240 | SHIM¤ 0.2MM (KIT) | 1003- | |
| 18 | 01000-31645 | BOLT | 1038- | |
| GD371F344 | STUD | 1003-1037 | ||
| 01510-31619 | NUT | 1003-1037 | ||
| 04050-14035 | PIN | 1003-1037 | ||
| 19 | 01602-21648 | WASHER | 1038- | |
| 20 | 232-23-12250 | CAGE | 1003- | |
| 21 | 232-23-12260 | GASKET (KIT) | 1003- | |
| 22 | 232-23-12270 | BOLT | 1003- | |
| 23 | 01000-31435 | BOLT | 1003- | |
| 24 | 01602-21442 | WASHER | 1003- | |
| 25 | 232-23-12311 | SHAFT | 1058- | |
| GD372F306 | SHAFT | 1003-1057 | ||
| 26 | 232-23-12320 | GEAR | 1003- | |
| 27 | 232-23-12330 | RING | 1003- | |
| 28 | 232-23-12340 | SHAFT | 1003- | |
| 29 | 06000-06312 | BEARING | 1003- | |
| 30 | 232-23-12350 | GASKET (KIT) | 1003- | |
| 31 | 232-23-12360 | O-RING (KIT) | 1058- | |
| GD371F347A | O-RING (KIT) | 1003-1057 | ||
| 32 | 01640-23345 | WASHER | 1003- | |
| 33 | 01511-33320 | NUT | 1003- | |
| 34 | 04050-16060 | PIN | 1003- |
