| Item | Part No. | Part Name | Qty | Serial No. |
| (708-25-04051) | PUMP ASS'Y | | .- |
| (\0\708-25-04014) | PUMP ASS'Y | | K20001-. |
| | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.6101 TO 6151. | | |
| (708-25-04151) | PUMP SUB ASS'Y | | .- |
| (\0\708-25-04112) | PUMP SUB ASS'Y | | K20001-. |
| | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.6111 TO 6113. | | |
| (\7\708-25-00100) | CASE ASS'Y,REAR | | K20001- |
| 1 | \6\ | CASE,REAR | | K20001- |
| 2 | \6\ | PLUG | | K20001- |
| (\7\708-25-00041) | CRADLE ASS'Y,REAR | | K20001- |
| (\7\708-25-00490) | CRADLE SUB ASS'Y,REAR | | K20001- |
| 3 | \6\ | CRADLE,REAR | | K20001- |
| 4 | \6\ | PLUG | | K20001- |
| 5 | (\7\708-25-13411) | CAM,ROCKER | | K20001- |
| 6 | (\7\708-25-12330) | JOINT | | K20001- |
| 7 | (\7\07000-22015) | O-RING | | K20001- |
| 8 | (\7\708-25-12340) | O-RING | | K20001- |
| 9 | (\7\708-25-12350) | BOLT | | K20001- |
| 10 | (\7\708-25-12360) | PLATE | | K20001- |
| 11 | (\7\04020-00820) | PIN,DOWEL | | K20001- |
| 12 | (\7\01010-30816) | BOLT | | K20001- |
| 13 | (\7\708-25-32720) | SHAFT,REAR | | K20001- |
| 14 | (\7\708-25-12731) | BEARING | | K20001- |
| 15 | (\7\708-25-05010) | WASHER KIT | | K20001- |
| \6\ | WASHER¤ 2.0MM | | K20001- |
| \6\ | WASHER¤ 2.1MM | | K20001- |
| \6\ | WASHER¤ 2.2MM | | K20001- |
| 16 | (\7\708-25-12790) | RING,SNAP | | K20001- |
| (\7\708-25-00411) | CYLINDER BLOCK ASS'Y,CYLINDER | | .- |
| (\7\708-25-00410) | BLOCK ASS'Y,CYLINDER | | K20001-. |
| 17 | (\7\708-25-13151) | BLOCK,CYLINDER | | K20001- |
| 18 | (\7\708-25-13621) | PLATE,VALVE | | .- |
| \0\708-25-13620 | PLATE,VALVE | | K20001-. |
| 19 | (\7\708-25-13630) | RING | | K20001- |
| 20 | (\7\708-25-13422) | RETAINER,SHOE | | K20001- |
| 21 | (\7\708-25-13120) | WASHER | | K20001- |
| 22 | (\7\708-25-13130) | SPRING | | K20001- |
| 23 | (\7\708-25-13140) | RING,SNAP | | K20001- |
| 24 | (\7\708-25-13312) | PISTON SUB ASS'Y | | K20001- |
| 25 | (\7\708-25-05061) | SPACER KIT | | K20001- |
| \6\ | SPACER¤ 11.540MM | | K20001- |
| \6\ | SPACER¤ 11.560MM | | K20001- |
| \6\ | SPACER¤ 11.575MM | | K20001- |
| 26 | (\7\708-25-13441) | RETAINER | | K20001- |
| 27 | (\7\708-25-13470) | SCREW | | K20001- |
| 28 | (\7\01643-30623) | WASHER | | K20001- |
| 29 | (\7\708-25-14112) | PISTON | | K20001- |
| 30 | (\7\708-25-14140) | CAP | | K20001- |
| 31 | (\7\708-25-14150) | CAP | | K20001- |
| 32 | (\7\708-25-14121) | SLIDER | | K20001- |
| 33 | 708-25-14130 | SPRING | | K20001- |
| 34 | (\7\708-25-05050) | SHIM KIT | | K20001- |
| \6\ | SHIM¤ 0.1MM | | K20001- |
| \6\ | SHIM¤ 0.2MM | | K20001- |
| \6\ | SHIM¤ 0.5MM | | K20001- |
| \6\ | SHIM¤ 0.1MM | | K20001- |
| 35 | 07000-02065 | O-RING | | K20001- |
| 36 | 01016-31035 | BOLT | | K20001- |
| 37 | 01643-31032 | WASHER | | K20001- |
| 38 | (\7\708-25-12970) | RING,SNAP | | K20001- |
| 39 | 07044-02412 | PLUG | | K20001- |
| 40 | 07002-02434 | O-RING | | K20001- |
| 41 | 04530-01018 | BOLT,EYE | | K20001- |
