| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 56B-61-13550 | Hose | 7079- | |
| 2 | 56B-61-13560 | Hose | 7079- | |
| 3 | 08210-01803 | Tube, Spiral | 7259- | |
| 4 | 56B-61-24310 | Clip | 7079- | |
| 5 | 07095-00630 | Cushion | 7079- | |
| 6 | (56B-61-11423) | Tube | - | |
| (56B-61-11423) | Tube | - |
- Главная
- Каталог запчастей
- Самосвалы
- Hm400 2r s/n 7079 up
- Hydraulic system
- Hydraulic piping, radiator piping (1/2) (#7259 )
Поиск по каталогу
Hydraulic Piping, Radiator Piping (1/2) (#7259-)
