| Item | Part No. | Part Name | Qty | Serial No. |
| 6536-01-0210 | Komatsu Diesel Particulate Filter (KDPF) Assembly | 85161- | ||
| 1 | 6536-11-1120 | Body | 85161- | |
| 2 | 6536-21-1010 | Body | 85161- | |
| 3 | 6536-31-1110 | Body | 85161- | |
| 4 | 6536-41-1010 | Body | 85161- | |
| 5 | 6526-91-1040 | Gasket | 85161- | |
| 6 | 6536-91-1040 | Plate | 85161- | |
| 7 | 6536-91-1140 | Plate | 85161- | |
| 8 | 01435-01040 | Bolt | 85161- | |
| 9 | 01584-01008 | Nut | 85161- | |
| 10 | 6536-91-4040 | Plate | 85161- | |
| 11 | 6536-91-4050 | Plate | 85161- | |
| 12 | 01435-01045 | Bolt | 85161- | |
| 13 | 01584-01008 | Nut | 85161- | |
| 14 | 6536-91-1030 | Gasket | 85161- | |
| 15 | 6536-91-1040 | Plate | 85161- | |
| 16 | 6536-91-1050 | Plate | 85161- | |
| 17 | 01435-01040 | Bolt | 85161- | |
| 18 | 01584-01008 | Nut | 85161- | |
| 19 | 6526-91-1040 | Gasket | 85161- | |
| 20 | 6536-91-1040 | Plate | 85161- | |
| 21 | 6536-91-1130 | Plate | 85161- | |
| 22 | 01435-01040 | Bolt | 85161- | |
| 23 | 01584-01008 | Nut | 85161- | |
| 24 | 6536-81-1010 | Bracket | 85161- | |
| 25 | 600-816-2910 | Sensor, Pressure | 85161- | |
| 26 | 01435-00630 | Bolt | 85161- | |
| 27 | 6526-91-4010 | Band | 85161- | |
| 28 | 6526-81-1030 | Tube | 85161- | |
| 29 | 6520-81-1080 | Connector | 85161- | |
| 30 | 6520-81-1060 | Hose | 85161- | |
| 31 | 07285-00115 | Clip | 85161- | |
| 32 | 600-052-3080 | Clip | 85161- | |
| 33 | 01435-01016 | Bolt | 85161- | |
| 34 | 6217-71-6650 | Clamp | 85161- | |
| 35 | 6217-71-6640 | Clamp | 85161- | |
| 36 | 01435-00625 | Bolt | 85161- | |
| 37 | 6526-81-1020 | Tube | 85161- | |
| 38 | 6520-81-1080 | Connector | 85161- | |
| 39 | 6520-81-1060 | Hose | 85161- | |
| 40 | 07285-00115 | Clip | 85161- | |
| 41 | 600-052-3080 | Clip | 85161- | |
| 42 | 01435-01030 | Bolt | 85161- | |
| 43 | 6526-91-1060 | Spacer | 85161- | |
| 44 | 600-816-2510 | Sensor, Temperature | 85161- | |
| 45 | 01435-00625 | Bolt | 85161- | |
| 46 | 6536-91-4060 | Plate | 85161- | |
| 47 | 6526-91-1080 | Spacer | 85161- | |
| 48 | 6536-91-4030 | Plate | 85161- | |
| 49 | 01435-01040 | Bolt | 85161- | |
| 50 | 01584-01008 | Nut | 85161- |
