| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 427-54-11255 | BRACKET,L.H. | 10501-@ | |
| 1 | \0\427-54-11254 | BRACKET,L.H. | 10052-10499 | |
| 2 | 427-54-11265 | BRACKET,R.H. | 10501-@ | |
| 2 | \0\427-54-11264 | BRACKET,R.H. | 10052-10499 | |
| 3 | 01010-81645 | BOLT | 10001-@ | |
| 4 | 01643-31645 | WASHER | 10001-@ | |
| 5 | 427-54-13242 | BRACKET | 10501-@ | |
| 5 | 427-54-13241 | BRACKET | 10052-10499 | |
| 6 | 427-54-12520 | BRACKET | 10052-10499 | |
| 7 | 01010-81640 | BOLT | 10501-@ | |
| 7 | 01010-51640 | BOLT | 10052-10499 | |
| 8 | 01643-31645 | WASHER | 10501-@ | |
| 8 | 01643-31645 | WASHER | 10052-10499 | |
| 9 | 01435-01225 | BOLT | 10501-@ | |
| 9 | \0\01010-51230 | BOLT | 10052-10499 | |
| 10 | 01643-31232 | WASHER | 10052-10499 | |
| 11 | 427-54-11231 | BRACKET,L.H. | 10593-@ | |
| 11 | \3\427-54-11230 | BRACKET,L.H. | 10001-10592 | |
| (427-54-11231,427-54-13740) | ||||
| 12 | 427-54-11241 | BRACKET,R.H. | 10001-@ | |
| 12 | 427-Z02-1180 | BRACKET,R.H. (FOR WATER SEPARATOR) | 10501-@ | |
| 13 | 01435-01220 | BOLT | 10501-@ | |
| 13 | \0\01010-51225 | BOLT | 10001-10499 | |
| 14 | 01643-31232 | WASHER | 10001-10499 | |
| 15 | 427-54-11270 | BAR,L.H. | 10001-@ | |
| 16 | 427-54-11280 | BAR,R.H. | 10001-@ | |
| 17 | 01435-01220 | BOLT | 10501-@ | |
| 17 | \0\01010-51230 | BOLT | 10001-10499 | |
| 18 | 01435-01225 | BOLT | 10501-@ | |
| 18 | \0\01010-51225 | BOLT | 10001-10499 | |
| 19 | 01643-31232 | WASHER | 10001-10499 | |
| 20 | 427-54-11831 | ANGLE | 10034-@ | |
| 21 | 01435-01230 | BOLT | 10501-@ | |
| 21 | 01010-51230 | BOLT | 10001-10499 | |
| 22 | 01643-31232 | WASHER | 10001-10499 | |
| 23 | 427-54-13120 | BRACKET,(FOR JAPAN) | 10052-@ | |
| 23 | 427-54-13120 | BRACKET,(EXCEPT JAPAN) | 10040-@ | |
| 24 | 01435-01245 | BOLT | 10501-@ | |
| 24 | 01010-51245 | BOLT | 10001-10499 | |
| 25 | 01643-31232 | WASHER | 10001-10499 | |
| 26 | 427-54-11823 | COVER,L.H. | 10526-10559 | |
| 26 | \0\427-54-11822 | COVER,L.H. | 10001-10525 | |
| 27 | 427-54-11770 | SEAL | 10001-@ | |
| 28 | 427-54-11813 | COVER,R.H. | 10516-10559 | |
| 28 | \0\427-54-11812 | COVER,R.H. | 10001-10515 | |
| 29 | 427-54-11760 | SEAL | 10001-@ | |
| 30 | 427-54-13450 | COVER,L.H. | 10501-10559 | |
| 30 | 427-54-11791 | COVER,L.H. | 10001-10499 | |
| 31 | 427-54-13460 | COVER,R.H. | 10501-10559 | |
| 31 | 427-54-11781 | COVER,R.H. | 10001-10499 | |
| 32 | 427-54-11750 | SEAL | 10001-@ | |
| 33 | 427-54-11860 | SPACER | 10001-@ | |
| 34 | 415-46-11380 | CUSHION | 10001-@ | |
| 35 | 01640-22232 | WASHER | 10001-@ | |
| 36 | 01435-01235 | BOLT | 10501-@ | |
| 36 | \0\01010-51235 | BOLT | 10001-10499 | |
| 37 | 01435-01240 | BOLT | 10501-@ | |
| 37 | \0\01010-51240 | BOLT | 10001-10499 | |
| 38 | 01643-31232 | WASHER | 10025-10499 | |
| 39 | 01580-11210 | NUT | 10025-@ | |
| 40 | 427-54-13680 | RUBBER | 10526-10559 | |
| 41 | 427-54-13690 | PLATE | 10526-10559 | |
| 42 | 04050-13020 | PIN,COTTER | 10526-10559 |
