ELECTRICAL SYSTEM (TRANSMISSION CONTROL HARNESS)(#12503-)

Item	Part No.	Part Name	Qty	Serial No.
1	235-06-36463	WIRING HARNESS		12503-
2	01010-81020	BOLT		12503-
3	01643-31032	WASHER		12503-
4	07095-20211	CUSHION		12503-
5	04434-51710	CLIP		12503-
6	235-06-45171	BRACKET		12503-
7	01010-81020	BOLT		12503-
8	01643-31032	WASHER		12503-
9	155-61-15350	CLIP		12503-
10	07095-00630	CUSHION		12503-
11	01010-81020	BOLT		12503-
12	01643-31032	WASHER		12503-
13	08053-01510	CLIP		12503-
14	01010-81016	BOLT		12503-
15	01643-31032	WASHER		12503-
16	04434-53411	CLIP		12503-
17	01010-81020	BOLT		12503-
18	01643-31032	WASHER		12503-
19	04434-51410	CLIP		12503-
20	01010-81016	BOLT		12503-
21	01643-31032	WASHER		12503-
22	04434-53211	CLIP		12503-
23	01010-81016	BOLT		12503-
24	01643-31032	WASHER		12503-
25	421-62-11940	PLATE		12503-
26	581-04-22290	CLIP		12503-
27	01010-81020	BOLT		12503-
28	01643-31032	WASHER		12503-
29	04434-51410	CLIP		12503-
30	23S-54-53240	FINISHER		12503-
31	7861-92-2330	SENSOR,TRANSMISSION REVOLUTION		12503-
32	07005-02216	SEAL, WASHER		12503-
33	04434-51410	CLIP		12503-
34	01010-81016	BOLT		12503-
35	01643-31032	WASHER		12503-
36	04434-52110	CLIP		12503-
37	04434-52110	CLIP		12503-
38	01010-81020	BOLT		12503-
39	01643-31032	WASHER		12503-
40	04434-51410	CLIP		12503-
41	01010-81016	BOLT		12503-
42	01643-31032	WASHER		12503-
43	04434-51410	CLIP		12503-
44	04434-50808	CLIP		12503-
45	235-06-31552	COVER		12503-
46	235-06-31570	SEAL		12503-
47	01010-80885	BOLT		12503-
48	01643-30823	WASHER		12503-
49	01010-81020	BOLT		12503-
50	01643-31032	WASHER		12503-
51	235-06-35730	COVER		12503-
52	235-06-35721	COVER		12512-
52	235-06-35720	COVER		12503-12511
53	01010-80812	BOLT		12503-
54	01643-30823	WASHER		12503-
