| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 08057-22012 | CLIP | A86001-- | |
| 2 | 01010-81225 | BOLT | A86001-- | |
| 3 | 01643-31232 | WASHER | A86001-- | |
| 4 | 08057-22012 | CLIP | A86001-- | |
| 5 | 01010-81225 | BOLT | A86001-- | |
| 6 | 01643-31232 | WASHER | A86001-- | |
| 7 | 08057-22012 | CLIP | A86001-- | |
| 8 | 142-03-11160 | SPACER | A86001-- | |
| 9 | 01010-81260 | BOLT | A86001-- | |
| 10 | 01643-31232 | WASHER | A86001-- | |
| 11 | 08057-12012 | CLIP | A86001-- | |
| 12 | 01010-81225 | BOLT | A86001-- | |
| 13 | 01643-31232 | WASHER | A86001-- | |
| 14 | 04434-53212 | CLIP | A86001-- | |
| 15 | 07095-20523 | CUSHION | A86001-- | |
| 16 | 01010-81225 | BOLT | A86001-- | |
| 17 | 01643-31232 | WASHER | A86001-- | |
| 18 | 207-06-75190 | BRACKET | A86001-- | |
| 19 | 01010-80855 | BOLT | A86001-- | |
| 20 | 01643-30823 | WASHER | A86001-- | |
| 21 | 04434-53212 | CLIP | A86001-- | |
| 22 | 198-06-53610 | BUSHING | A86001-- | |
| 23 | 01010-81225 | BOLT | A86001-- | |
| 24 | 01643-31232 | WASHER | A86001-- | |
| 25 | 08028-44035 | CABLE | A86001-- | |
| 26 | 01010-81020 | BOLT | A86001-- | |
| 27 | 01643-31032 | WASHER | A86001-- | |
| 28 | 08038-02027 | CAP | A86001-- | |
| N/I | 08038-00519 | CAP | A86001-- |
