Item | Part No. | Part Name | Qty | Serial No. |
1 | 20Y-978-1101 | COOLER ASS'Y | 58019- | |
2 | 20Y-978-1240 | HOSE ASS'Y | 45001- | |
3 | 01010-51220 | BOLT | 45001- | |
4 | 01643-31232 | WASHER | 45001- | |
5 | 207-978-5230 | PLATE | 45001- | |
6 | 207-978-5240 | PLATE | 45001- | |
7 | 01010-51235 | BOLT | 45001- | |
8 | 01643-31232 | WASHER | 45001- | |
9 | 20Y-978-1181 | HOSE | 58019- | |
10 | 20Y-978-1120 | COMPRESSOR | 45001- | |
10 | TW7041-0180 | SWITCH | 45001- | |
10A | 07000-02016 | O-RING | 45001- | |
11 | 20Y-978-1131 | BRACKET | 58019- | |
12 | 01010-50865 | BOLT | 58019- | |
13 | 01643-30823 | WASHER | 45001- | |
14 | 01010-51075 | BOLT | 51129- | |
15 | 01010-51085 | BOLT | 51129- | |
16 | 01643-31032 | WASHER | 51129- | |
17 | 01252-41030 | BOLT | 58019- | |
18 | 01010-51040 | BOLT | 58019- | |
19 | 01643-31032 | WASHER | 58019- | |
20 | 20Y-978-1340 | V-BELT | 58019- | |
21 | 20Y-978-1161 | HOSE | 58019- | |
22 | 20Y-978-1201 | CONDENSER ASS'Y | 58019- | |
23 | 20Y-978-1110 | RECEIVER | 58019- | |
24 | 20Y-978-1171 | HOSE | 58019- | |
25 | 202-981-1370 | DRUM | 45001- | |
26 | 08034-00823 | BAND | 58019- |
