| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 21M-62-11690 | Bracket | 65001- | |
| 2 | 01010-81230 | Bolt | 65001- | |
| 3 | 175-54-34170 | Washer | 65001- | |
| 4 | 21M-62-11221 | Block | 65001- | |
| 5 | 07040-11812 | Plug | 65001- | |
| 6 | 07002-11823 | O-ring | 65001- |
- Главная
- Каталог запчастей
- Гусеничные экскаваторы
- Pc650lc 8e0 s/n 65001 up
- Hydraulic system
- Boom piping, bracket (#65001 )
Поиск по каталогу
Boom Piping, Bracket (#65001-)
