| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 04434-53212 | CLIP | 76001- | |
| 2 | 01010-81225 | BOLT | 76001- | |
| 3 | 01643-31232 | WASHER | 76001- | |
| 4 | 09415-02512 | CAP | 76001- | |
| 5 | 09304-10835 | KNOB | 76001- | |
| 6 | 14X-98-11250 | PLATE, OPERATING | 76001- |
- Главная
- Каталог запчастей
- Бульдозеры
- D155ax 5 s/n 70001 up
- Operator's compartment and control system
- Blade control lever and knob (tilt dozer)(#76001 )
Поиск по каталогу
BLADE CONTROL LEVER AND KNOB (TILT DOZER)(#76001-)
