| Item | Part No. | Part Name | Qty | Serial No. |
| G-1 | (\8\707-01-XY020) | CYLINDER GROUP,L.H. (FINAL COATING) | 31001- | |
| G-2 | (\8\707-01-XY030) | CYLINDER GROUP,R.H. (FINAL COATING) | 31001- | |
| ==================== | ||||
| 707-01-0A510 | CYLINDER ASS'Y | 31001- | ||
| 1 | 707-13-20150 | CYLINDER | 31001- | |
| 2 | 707-46-13010 | BUSHING | 30001- | |
| 3 | 07043-00108 | PLUG | 30001- | |
| 4 | 707-27-20960 | HEAD,CYLINDER | 31001- | |
| 5 | 707-51-14080 | PACKING,ROD (KIT) | 30001- | |
| 6 | 707-51-14640 | RING,BUFFER (KIT) | 31001- | |
| 7 | 707-52-91170 | BUSHING | 31001- | |
| 8 | 198-63-93170 | SEAL,DUST (KIT) | 30001- | |
| 9 | 07179-14160 | RING,SNAP | 30001- | |
| 10 | 07000-15190 | O-RING (KIT) | 31001- | |
| 11 | 707-35-92020 | RING,BACK-UP (KIT) | 31001- | |
| 12 | 07000-15190 | O-RING (KIT) | 31001- | |
| 13 | 707-35-92020 | RING,BACK-UP (KIT) | 31001- | |
| 14 | 707-71-32970 | COLLAR | 31001- | |
| 15 | 01011-82705 | BOLT | 30001- | |
| 16 | 01643-32780 | WASHER | 30001- | |
| 17 | 209-63-53320 | ROD,PISTON | 31001- | |
| 18 | 707-46-11520 | BUSHING | 30001- | |
| 19 | 07043-00108 | PLUG | 30001- | |
| 20 | 707-36-20430 | PISTON | 31001- | |
| 21 | 07000-15130 | O-RING (KIT) | 31001- | |
| 22 | 07001-05130 | RING,BACK-UP (KIT) | 31001- | |
| 23 | 707-44-20910 | RING | 30001- | |
| 24 | 707-39-20820 | RING,WEAR (KIT) | 30001- | |
| 25 | 707-44-20180 | RING,PISTON (KIT) | 30001- | |
| 26 | 01310-01232 | SCREW | 31001- | |
| 27 | 707-71-61500 | PLUNGER | 31001- | |
| 28 | 707-86-11640 | TUBE,L.H. | 31001- | |
| 28 | 707-86-11660 | TUBE,R.H. | 31001- | |
| 29 | 707-86-11650 | TUBE,L.H. | 31001- | |
| 29 | 707-86-11670 | TUBE,R.H. | 31001- | |
| 30 | 07000-13038 | O-RING (KIT) | 30001- | |
| 31 | 01010-81245 | BOLT | 30001- | |
| 32 | 01643-31232 | WASHER | 30001- | |
| 33 | 07378-11210 | HEAD | 30001- | |
| 34 | 07371-51260 | FLANGE | 30001- | |
| 35 | 01010-81245 | BOLT | 30001- | |
| 36 | 01643-31232 | WASHER | 30001- | |
| 37 | 707-88-96110 | BAND | 30001- | |
| 38 | 707-88-22730 | BRACKET | 31001- | |
| 39 | 01010-81240 | BOLT | 30001- | |
| 40 | 01643-31232 | WASHER | 30001- | |
| 41 | 07283-33442 | CLIP | 30001- | |
| 42 | 01599-01011 | NUT | 30001- | |
| 43 | 01643-31032 | WASHER | 30001- | |
| ==================== | ||||
| 707-99-77300 | SERVICE KIT | 31001- |
