| Item | Part No. | Part Name | Qty | Serial No. |
| (709-36-13402) | VALVE ASS'Y | | 3401- |
| (\2\709-36-13401) | VALVE ASS'Y | | (3401-4049) |
| (709-36-12302) | VALVE ASS'Y | | 1001-3400 |
| (\2\709-36-12301) | VALVE ASS'Y | | (2729-.) |
| (\2\709-36-12300) | VALVE ASS'Y | | (1001-2728) |
| 709-30-63702 | VALVE ASS'Y,SUCTION AND SAFETY | | 1001- |
| (\2\709-30-63300) | VALVE ASS'Y,SUCTION AND SAFETY | | (1001-2728) |
| 1 | 709-30-62110 | SLEEVE | | 1001- |
| 2 | \6\ | VALVE | | 2729- |
| 2 | \6\ | VALVE | | 1001-2728 |
| 3 | \6\ | SEAL | | 1001- |
| 4 | \6\ | POPPET | | 2729- |
| 4 | \6\ | POPPET | | 1001-2728 |
| 5 | \6\ | SPRING | | 2729- |
| 5 | \6\ | SPRING | | 1001-2728 |
| 6 | \6\ | PISTON | | 1001-2728 |
| 7 | \6\ | SCREW | | 2729- |
| 8 | \6\ | PISTON | | 2729- |
| 9 | \6\ | SEAL | | 2729- |
| 10 | \6\ | O-RING | | 1001- |
| 11 | \6\ | NUT | | 1001- |
| 12 | 700-20-62170 | SPRING | | 1001- |
| 13 | 709-30-62150 | PLUG | | 1001- |
| 14 | 07002-12034 | O-RING | | 1001- |
| 15 | 07002-02034 | O-RING | | 1001- |
| 709-30-64500 | VALVE ASS'Y,SUCTION AND SAFETY | | 1001- |
| (\2\709-30-62400) | VALVE ASS'Y,SUCTION AND SAFETY | | (1001-2728) |
| 16 | 709-30-62110 | SLEEVE | | 1001- |
| 17 | \6\ | VALVE | | 2729- |
| 17 | \6\ | VALVE | | 1001-2728 |
| 18 | \6\ | SEAL | | 1001- |
| 19 | \6\ | POPPET | | 2729- |
| 19 | \6\ | POPPET | | 1001-2728 |
| 20 | \6\ | SPRING | | 1001- |
| 21 | \6\ | PISTON | | 1001-2728 |
| 22 | \6\ | SCREW | | 2729- |
| 23 | \6\ | PISTON | | 2729- |
| 24 | \6\ | SEAL | | 2729- |
| 25 | \6\ | O-RING | | 1001- |
| 26 | \6\ | NUT | | 1001- |
| 27 | 700-20-62170 | SPRING | | 1001- |
| 28 | 709-30-62150 | PLUG | | 1001- |
| 29 | 07002-12034 | O-RING | | 1001- |
| 30 | 07002-02034 | O-RING | | 1001- |
| 709-30-61100 | VALVE ASS'Y,SUCTION | | 1001- |
| 31 | 709-30-61110 | SLEEVE | | 1001- |
| 32 | \6\ | VALVE | | 1001- |
| 33 | 700-20-62170 | SPRING | | 1001- |
| 34 | \6\ | SEAL | | 1001- |
| 35 | 07002-02034 | O-RING | | 1001- |
